Bow | Hybrid Absorbers-Diffusers
Features
Type:
Hybrid Absorber
Recommended for:
Studios | Recording rooms
Absorption Range:
160 Hz to 4000 Hz
Acoustic Class:
D | (αw) = 0,5
Purpose
Available in 3 sizes, all crafted from premium fabrics and quality wood, filled with high-performance acoustic foam.
Combining the 3 different sizes of Bow creates distinct, unique designs and diffusion patterns.
The Bow can be installed on walls or ceilings, hung on screws by means of a discreet imbedded backboard. It can also be installed directly through the front of the panel, concealed behind removable side-foam.
The Bow range is a new design born of the collaboration between Jan Morel and Artnovion.
The bow is an elegant balance between simplicity and futuristic design. The Bow is available in 3 different sizes.
Each Bow has a solid wooden shell, forming a carefully calibrated semi-circular diffuser, with dual lateral closed cavities packed with high-performance acoustic foam. The Bow has a further central Helmholtz cavity extending the mid-range frequency absorption, for an overall balanced mid-high frequency hybrid absorber with an outstanding geometric diffusion.
The bow is an elegant balance between simplicity and futuristic design. The Bow is available in 3 different sizes.
Each Bow has a solid wooden shell, forming a carefully calibrated semi-circular diffuser, with dual lateral closed cavities packed with high-performance acoustic foam. The Bow has a further central Helmholtz cavity extending the mid-range frequency absorption, for an overall balanced mid-high frequency hybrid absorber with an outstanding geometric diffusion.

Performance
S
/
M
/
L
/
Scattering coefficient

Jan Morel Signature line
This product is available in the following Fire Rate:
FG | Furniture Grade
_______
PRODUCT COMPOSITION:
Bow Absorber | Natural wood veneer (FG)
- Natural wood veneer
- Acoustic fabric
- Marine-grade plywood structural frame
- Calibrated cell acoustic foam
Bow Absorber | Lacquered HMDF (FG)
- Lacquered HMDF
- Acoustic fabric
- Marine-grade Plywood Structural Frame
- Calibrated Cell Acoustic Foam
_______
Range Dimensions:
Bow - S | 595x148x75mm
Bow - M | 892x148x107mm
Bow - L | 1190x148x138mm
FG | Furniture Grade
_______
PRODUCT COMPOSITION:
Bow Absorber | Natural wood veneer (FG)
- Natural wood veneer
- Acoustic fabric
- Marine-grade plywood structural frame
- Calibrated cell acoustic foam
Bow Absorber | Lacquered HMDF (FG)
- Lacquered HMDF
- Acoustic fabric
- Marine-grade Plywood Structural Frame
- Calibrated Cell Acoustic Foam
_______
Range Dimensions:
Bow - S | 595x148x75mm
Bow - M | 892x148x107mm
Bow - L | 1190x148x138mm

Bow Absorber | Range
Overview
Features
Type:Hybrid Absorber
Recommended for:
Studios | Recording rooms
Absorption Range:
160 Hz to 4000 Hz
Acoustic Class:
D | (αw) = 0,55
Dimensions:
595x148x75mm
Available Finishes:
FabricFeatures
Type:Hybrid Absorber
Recommended for:
Studios | Recording rooms
Absorption Range:
160 Hz to 4000 Hz
Acoustic Class:
D | (αw) = 0,5
Dimensions:
892x148x107mm
Available Finishes:
FrontFeatures
Type:Hybrid Absorber
Recommended for:
Studios | Recording rooms
Absorption Range:
160 Hz to 4000 Hz
Acoustic Class:
D | (αw) = 0,5
Dimensions:
1190x148x138mm
