Vector Doble W - Bass Trap - Wall

Features

Type:
Pistonic Diaphragmatic Absorber
Absorption Range: 80 Hz to 120 Hz
Peak Absorption Frequency: 90 Hz

Purpose
  - Room mode control
 - Bass ratio control
 - Low frequency RT reduction
 - Improving low frequency response
 - Reducing low frequency time decay
The Vector Wall Bass Trap is ideal for rooms with low frequency issues, taking full advantage of it small depth to place on walls alongside existing room treatment. With a peak absorption from 80 Hz to 120 Hz the Vector Wall Bass Trap is the bridge between the low and mid frequency absorptions, acting in the “low-high” frequency range.
The Vector Wall Bass Trap is equipped with a double membrane surrounding a central acoustic core. This design allows for a larger membrane - lowering the resonant frequency, whilst increasing the volume of the inner air cavities – packing the most performance into the least volume possible.
Its distinctive design offers a impressive, unique look to your studio, a true trademark of Jan Morel design.
Performance

1/3 Oct. from 32Hz to 160Hz | 1 Oct. from 250Hz to 8 KHz

Invisible Bass Trapping

Recommended for
 - Vertical Wall
- Small Room Acoustics
- Acoustic pressure zones
Pistonic Diaphragmatic Absorber Pressure Core
High Density velocity Core
Effective in both velocity and pressure modal zones
Maximum performance, minimum thickness.


This product is available in the following Fire Rate:
FG | Furniture Grade

_______

PRODUCT COMPOSITION:

Vector Doble W - Bass Trap - Wall | Natural Wood
- Natural wood
- Acoustic fabric
- Marine-grade plywood structural frame
- Calibrated cell acoustic foam

Vector Doble W - Bass Trap - Wall | Lacquered Wood
- Lacquered wood
- Acoustic fabric
- Marine-grade plywood structural frame
- Calibrated cell acoustic foam

_______

Dimensions:
Vector Doble W - Bass Trap - Wall | 595x1190x58mm
- Equipped with eight M6 Screw Thread receiver


These panels can only be installed on vertical walls. Not for ceiling use.


Fixing Systems: Fixart Tube
FixArt Tube is a innovative system for acoustic panels. Easy to install, easy to align, Simply follow our template and attach the clip fixture to your surface, and then to the corners of your panel, clip them both into the tube, and you're done! With easy adjustment once mounted, and an easy clip-in, clip-out.

Vector Doble W - Bass Trap - Wall

Overview

Features
Type:
Pistonic Diaphragmatic Absorber
Absorption Range: 80 Hz to 120 Hz
Peak Absorption Frequency: 90 Hz
Purpose
  - Room mode control
 - Bass ratio control
 - Low frequency RT reduction
 - Improving low frequency response
 - Reducing low frequency time decay
Recommended for
 - Vertical Wall
- Small Room Acoustics
- Acoustic pressure zones
Dimensions:
595x1190x58mm

Available Finishes:

Front
Fabric

Configure your product and contact us for more information
